ARCPOD27Q

ARCPOD27Q is a compact high-power outdoor wash light featuring an outstanding brightness of 11,480 lumens. Equipped with 27x10W RGBW full colour LEDs, delivering superior colour mixing. The slim sizing, as well as the wide range of available optics through the magnet, makes the ARCPOD27Q an incredibly flexible and versatile device for large outdoor applications

Features:
27x10W RGBW/FC LEDs delivering 11'480 lumens
Compact form factor and fan-free

LIGHT SOURCE

Source: 27X10W RGBW/FC LEDs
CT: 5960K
CRI: 71.8
Luminous flux: @full 11480lm
Lux: 15° @full 11276lux @3m
Lux: 15° @full 4060lux @5m
Source life expectancy: >100.000 h

OPTICS

Beam angle: 15°
Field angle: 28°
Lens diameter: 36mm
Lens type: honeycomb gapless plano convex optics
Additional optics: 10°, 25°, 45°
Other: barn doors not included

COLOUR SYSTEM

Colour mixing: RGBW/FC
CTC: CTC control through independent DMX channel
Colour wheel: virtual colour wheel with presets
Macros: several pre-build macros with adjustable speed

DYNAMIC EFFECTS

Static colour mode: selection of static colour
Manual colour mode: manual adjustment of colour
Auto mode: built-in programs with execution speed adjustment

BODY

Tilt angle: +/- 90 ° Manual°
Body: sturdy die-cast aluminium body conceived for long-time durability
Body colour: grey

CONTROL

Protocols: DMX512, RDM
DMX channels: 5, 7, 10, 13channel
Pixel control: 3 horizontal individual sections controlled
RDM: RDM ready for fixture remote monitor and settings
Firmware upgrade: yes, via USB-DMX interface (UPBOX1) not included
Master/Slave: for synchronized operation of more units linked in a chain

ELECTRONICS

Dimmer: linear 0~100% electronic dimmer
Operating temperature: -20° ~ +50°
Flicker: flicker free operation
Selectable PWM: 600~25K Hz

ELECTRICAL

Power supply: 100-240V – 50/60Hz
Power consumption (at 230V): 268W
Power consumption (at 120V): 275W
Output (at 230V):9 units on a single power line
Output (at 120V): 5 units on a single power line
Power factor: 0,994

PHYSICAL

Cooling: natural cooling of the peculiar chassis and to absence of fans
Sospension and fixing: hanging bracket for floor positioning with
Signal connection: IP IN/OUT DMX connector
Power connection: IP IN/OUT power connector
IP rating: 65
Dimensions (WxHxD): 454x153x268.5mm
Weight: 9kg

ARCPOD27Q

ARCPOD36

ARCPOD36 is a wash light with a 36x8W RGBW/FC LED source designed for outdoor installations where a high performing projector with reliable brightness and chromatic precision is required. The rectangular shape design and the super-slim profile allow the ARCPOD36 to be easily integrated into any architectonic context whilst also integrate with outdoor (IP 65) projects and installations due to the construction of chassis in die-cast aluminium and tempered glass with no fans for ventilation. ARCPOD36 is a compact projector capable of lighting large spaces, both as a stage wash in temporary events and for architectural lighting projects

Features:
4D (RGBW) colour mixing
DMX virtual colour wheel
CTC
235W power consumption and LED source expected life of over 50.000 hours
User menu and settings are accessed through a 4 button touch-sensitive LED interface while 3 different DMX modes (4-10 channel) available

LIGHT SOURCE

Source: 36 x 8W RGBW/FC LEDs
Luminous flux: @full 7769lm
Lux: 15° @full 9429lux @3m
Lux: 15° @full 3395lux @5m
Source life expectancy: >50.000 h

OPTICS

Beam angle: 15°
Field angle: 22°
Additional optics:

25° / 45° (optional)

COLOUR SYSTEM

Colour mixing: RGBW/FC
White presets: 3200K~10000K
Colour wheel: virtual colour wheel with presets
Macros: several pre-build macros with adjustable speed

DYNAMIC EFFECTS

Static colour mode: selection of static colour
Manual colour mode: manual adjustment of colour
Auto mode: built-in programs with execution speed adjustment

BODY

Body: sturdy die-cast aluminium body conceived for long-time durability
Body colour: white

CONTROL

Protocols: DMX512
DMX channels: 4 / 6 / 10channel
Display: touch-sensitive LED display

Firmware upgrade: yes, via USB-DMX interface (UPBOX1) not included
Master/Slave: for synchronized operation of more units linked in a chain

ELECTRONICS

Dimmer: linear 0~100% electronic dimmer
Dimmer curves:4 different dimming curves available
Strobe / shutter: 1 - 30 Hz, electronic
Operating temperature: -20° ~ +50°
Flicker: flicker free operation

ELECTRICAL

Power supply:100-240V 50/60Hz
Power consumption (at 230V): 235W
Output (at 230V): 6 units on a single power line

PHYSICAL

Cooling:pressure and temperature balance through GORE membrane vents
Sospension and fixing: hanging bracket suitable for safe hanging and positioning
Adaptors: XLR and 16A adaptors included
Signal connection: IP connectors
Power connection: IP connector
IP rating: 65
Dimensions (WxHxD): 579x338x115mm
Weight: 16.66kg

ARCPOD36

ARCPAR18

ARCPAR18 is a wash light with 18x8W RGBW/FC LED source engineered for outdoor installations where a high-performance projector with superior brightness and chromatic precision is required. The round shape design and the super-slim profile allows the ARCPAR18 to be easily integrated into any architectonic design whether it be indoor or outdoor (IP 65) due to the construction of chassis in die-cast aluminium and tempered glass with no ventilation fans. ARCPAR18 is a compact projector capable of lighting large spaces both as a stage wash in temporary events and for architectural lighting projects and installations

Features:
4D (RGBW) colour mixing
DMX virtual colour wheel
CTC
Low 128W power consumption and LED source expected life of over 50000 hours
User menu and settings are accessed through a 4 button touch-sensitive LED interface while 3 different DMX modes (4-10 channel) available

LIGHT SOURCE
