MOVING HEAD
B19
The B19 is a 19x15W moving head zoom light. It features compact and unique honeycomb design, beam,wash, swirl, kaleidoscope effect. Bi-directional and continuous rotating front lens and 4-60° zoom angle which is idea for small and big application.
The B19 is a 19x15W moving head zoom light. It features compact and unique honeycomb design, beam,wash, swirl, kaleidoscope effect. Bi-directional and continuous rotating front lens and 4-60° zoom angle which is idea for small and big application.
Key features:
19x15W RGBW LED
Beam, wash or kaleido effects
Intelligent dyeing effect
Front lens Bi-directional Rotation
Zoom range from 4-60°,suitable for small and big applications
Individual control of each LED. With unique honeycomb designed lens
Beam edge feathering effect(wash mode)
Speed adjustable stop / strobe effect, with an instant light, dark field function
Technical Data
| Power supply: | AC100-240V, 50/60Hz |
| Light source: | 19x15W LED |
| Color mixing: | RGBW 4-in-1 |
| Pan: | 540° |
| Tilt: | 270° |
| Zoom scale: | 4°-60° motorized |
| Power connection: | PowerCON in&out |
| Signal connection: | 3-pin XLR in&out(5-pin optional) |
| DMX channels: | 21/23/35/78/92/97/99 |
| Control mode: | DMX 512, Sound, Auto program |
| Housing: | Colour black, ABS |
| Size: | 494 x 358 x 253mm(19.5 x 14.1 x 9.9in) |
| Package(carton): | 790 x 350 x 360mm(31.1 x 13.8 x 14.2in) |
| N.W.: | 15.5kg(34.2lb) |
| G.W.: | 20kg(44.1lb) |
| Accessories(included): | Power cable, safety rope |
| Accessories(optional): | Gobo holder, gel frame, clamp |
| Certificates: | CE |
| Environment: | IP20 |
Β19
Hero 300 Spot
The Hero 300 Spot is a LED spot light, and powered by a good output 200W white LED. Featuring 2 gobo wheels, 1 color wheel, prism, motorized focus, zoom and frost effect, as well as various dynamic effects.
Key features:
200W super brightness LED
Spot effect
1 Color wheel with 9 colors+open
1 Gobo wheel with 9 fixed gobo+open
1 Gobo wheel with 7 rotating gobo+open
Focus, Zoom, Frost effect
1 Gobo wheel with 7 rotating gobo+open
Focus, Zoom, Frost effect
3-facet prism
20/24 channel mode
Application:
Concerts
Night clubs
Large venues
Big stages and events
Technical Data
Technical Data
| Power supply: | AC100-240V, 50/60Hz |
| Light source: | 200W white LED |
| Pan: | 540° |
| Tilt: | 270° |
| Zoom: | 7~20° motorized |
| Focus: | Motorized |
| Strobe: | Electronic strobe |
| Color temperature: | 6600K |
| Color Rendition: | CRI 70 |
| Prism: | 3 facet circular rotating indexable prism |
| Static Gobo wheel: | 9 static gobos+open |
| Rotating Gobo wheel: | 7 rotating gobos+open |
| Color wheel: | 9 colors+open |
| Power connection: | PowerCON in |
| Signal connection: | 3 pin XLR in&out |
| DMX channels: | 16/20 |
| Control mode: | DMX 512, Auto, Sound, Master slave |
| Housing: | Colour black, ABS+PC |
| Size: | 334 x 270 x 509mm(13.2 x 10.6 x 20.1in) |
| Package(carton): | 410 x 360 x 610mm(16.1 x 14.2 x 24in) |
| N.W.: | 13.7kg(30.2lb) |
| Accessories(included): | Power cable, safety rope |
| Accessories(optional): | Clamp, DMX cable |
| Certificates: | CE, RoHs |
| Environment: | IP20 |
HERO 300 SPOT
Hero 300 Performance
The Hero 300 Performance is a hybrid moving head with beam, spot, wash, animation "all-in-one" effect, and powered by a great output 300W white LED. Featuring 2 gobo wheels, 1 animation wheel, CMY color mixing, prism, motorized focus, zoom and frost effect, as well as various dynamic effects.
Key features:
300W super brightness LED
Beam,Spot,Wash Animation effect all-in-one
CMY Coler Mixing System
1 Animation wheel with continuous bi-directional rotation
1 Color wheel with 7 colors＋open
1 Gobo wheel with 8 fixed gobo＋open
1 Gobo wheel with 7 rotating gobo＋open
Focus,Zoom,Frost,Dynamic effect
3-face prism
20/24 channel mode
Application:
Concerts
Night clubs
Large venues
Big stages and events
Technical Data:
| Power supply: | AC100-240V, 50/60Hz |
| Light source: | 300W white LED |
| Pan: | 540° |
| Tilt: | 270° |
| Zoom range: | 13°-44° motorized |
| Focus: | Motorized |
| Strobe: | Electronic strobe |
| Color temperature: | 6600K |
| Color Rendition: | CRI 70 |
| Prism: | 3 facet circular rotating indexable prism |
| Frost: | Frost filter |
| Static Gobo wheel: | 8 static gobos+open |
| Rotating Gobo wheel: | 7 rotating gobos+open |
| Animation Gobo : | Continuous bi-directional rotation animation wheel |
| Color wheel: | 7 colors+open |
| Power connection: | PowerCON in |
| Signal connection: | 3 pin XLR in&out(5-pin optional) |
| DMX channels: | 20/25 |
| Control mode: | RDM, DMX, Auto, Sound, Master slave |
| Housing: | Colour black, ABS+PC |
| Size: | 370 x 285 x 605mm(14.5 x 11.2 x 23.8in) |
| Package(carton): | 475 x 387 x 710mm(18.7 x 15.2 x 27.9in) |
| N.W.: | 18.6kg(41lb) |
| Accessories(included): | Power cable, safety rope |
| Accessories(optional): | Clamp, DMX cable |
| Certificates: | CE, RoHs |
| Environment: | IP20 |
HERO 300 PERFORMANCE
PROFILE SPOT
HONOR 300 ZOOM
Powered by 300W 3200K or 5600K LED, the Honor 300 Zoom is designed to replace the 1KW~1.5KW Tungsten Halogen profile light. The 18-38° "all-in-one" zoom range covers the most regular 19°, 26°, 36° lens. It creates a flat and even field of light and crisp pattern projection.
Order code:
60233 (WW-DMX)
60233 (WW-DMX)
60235 (CW-DMX)
60237 (WW-DMX, RDM, ArtNet)
60239 (CW-DMX, RDM, ArtNet)
Key features:
300W COB white LED
CRI 97, R9≥90, TLCI up to 98
HQ optical system, clean shutter cuts beam
18-38° "all-in-one" zoom range
16 bit dimming via DMX
Flicker free with selectable PWM
Rotary, key, DMX control of dimmer
Intelligent temperature control, silent operation for studio and theater use
Artnet, RDM function optional, 5 dimmer curves
Application:
Application:
Broadcast, HD studio
Theater, chruch
Event, venues
Museum
Exhibition lighting
Technical Data
| Power supply: | AC100-240V, 50/60Hz |
| Light source: | 300W COB LED |
| Color temperature: | 3200K/5600K optional |
| Zoom scale: | 18°-38° manually, 5°-10°, 9°-18° lens tube optional |
| Color Rendition: | CRI 97, R9≥90, TLCI 98(3200K), TLCI 96(5600k) |
| Power connection: | PowerCON in&out |
| Signal connection: | 3-pin XLR in&out(5-pin optional), Net in&out(optional) |
| DMX channels: | 1/2/3, 3CH mode for RDM version |
| Control mode: | Rotary, DMX, RDM(optional) |
| Housing: | Colour black, ABS+PC |
| Size: | 745 x 294 x 294mm(29.3 x 11.6 x 11.6in) |
| Package(carton): | 790 x 350 x 360mm(31.1 x 13.8 x 14.2in) |
| N.W.: | 8.7kg(19.2lb) |
| G.W.: | 11.5kg(25.4lb) |
| Accessories(included): | Power lead, Safety rope |
| Accessories(optional): | Gobo holder, Gel frame, Clamp |
| GOBO size: | OD 55mm, ID 50mm |
| Certificates: | CE, RoHs, ETL pending |
| Environment: | IP20 |
HONOR 300 ZOOM
Honor 350C Zoom
The Honor 350C Zoom is a 350W LED profile spot with RGBAYC color mixing. A good replacement of the tungsten source. The 18- 38° all-in-one zoom range covers the most regular 19°, 26°, 36° lens.
Key features:
350W RGBAYC six color LED
HQ optical system, clean shutter cuts beam
18-38° "all-in-one" zoom range
Flicker free with selectable PWM
High CRI of 90
16 bit dimming via DMX
Rotary, key, DMX control of dimmer
Intelligent temperature control
Artnet, RDM function
Technical Data
| Power supply: | AC100-240V, 50/60Hz |
| Light source: | 350W RGBAYC LED |
| Color mixing: | Red, Green, Blue, Amber, Yellow, Cyan |
| Zoom scale: | 18°-38° manually, 5°-10°, 9°-18° lens tube optional |
| Power connection: | PowerCON in&out |
| CRI: | 90Ra |
| DMX channels: | 2/7/9 |
| Control mode: | Rotary, DMX, RDM |
| Housing: | Colour black, ABS+PC |
| Size: | 745 x 294 x 294mm(29.3 x 11.6 x 11.6inch) |
| Package(carton): | 790 x 350 x 360mm(31.1 x 13.8 x 14.2inch) |
| N.W.: | 8.7kg(19.2lb) |
| G.W.: | 11.5kg(25.4lb) |
| Accessories(included): | Power lead, Safety rope |
| Accessories(optional): | Gobo holder, Gel frame, Clamp |
| GOBO size: | OD 55mm, ID 50mm |
| Certificates: | CE, RoHs, ETL pending |
| Environment: | IP20 |
Honor 350C Zoom
LED PANEL
Solar Panel 200
Solar Panel 200 is a 200Watt LED panel light with fan-free design. It comes with even and wide wash effect, super slim body, perfect control lighting area
through 8-leaf barn door. Moreover, equiped with solar spectrum LEDs which is healthy for human eyes, CRI 96, 99 TLCI brings perfect light quality. It is specially designed for TV studios, video shooting.
| Key features: |
| • 200Watt white LED, 3200K or 5600K CT |
| • Solar spectrum LEDS, healthy for human eyes |
| • Super bright, uniform coverage and even lighting |
| • Super slim body, handy weight |
| • Fan free design, no noise |
| • High CRI 96, TLCI 99 |
| • Support DMX and RDM protocols |
| • Dimmer curves selectable |
| • Smooth dimming, flicker free operation |
| • Dimmer frequency 1.2 - 20.0 KHz |
| • 8-leaf barn door |
| Technical Data | |
| Power supply: | AC100-240V, 50/60Hz |
| Light source: | 200W |
| Color temperature: | 3200K or 5600K |
| Color rendition: | CRI 97, R9≥90, TLCI 98, CQS 94 |
| Power connection: | PowerCON in & out |
| Signal connection: | 3-pin XLR in&out(5-pin opt.), Net in&out(opt.) |
| DMX channels: | 1 |
| Control mode: | DMX, RDM |
| Dimmer curves: | Standard / Stage / TV / Archi / Theatre |
| Housing: | Colour black, Aluminum |
| Size: | 686 x 103 x 298mm |
| N.W.: | 8.9 kg |
| Accessorries(include): | Power cable, barn door, Safety cable |
| Accessorries(optional): | Beehive diffuser, Clamp |
| Environment: | IP20 |
| Application: |
| • Broadcast, TV studio |
| • Film shooting |
| • Video shooting |
SOLAR PANEL 200
SKY PANEL 108
108 x 3W LED panel
| Key features: |
| • 108 x 3W SMD LED |
| • RGBW(27R, 27G, 27B, 27W) LED |
| • Even color mixing |
| • Aluminum housing |
| Technical Data | |
| Power supply: | AC100-240V, 50/60Hz |
| Light source: | 108 x 3W SMD LED |
| Color mixing: | RGBW(27R, 27G, 27B, 27W) LED |
| Beam angle: | 60°x120° |
| Power connection: | PowerCON in&out |
| Signal connection: | 3-pin XLR in&out |
| Control channels: | 8 |
| Control mode: | DMX 512 |
| Size: | 480 x 270 x 127mm |
| Package: | 505 x 200 x 125mm |
| N.W.: | 8.5 kg |
| G.W.: | 9.5 kg |
| Accessories: | Power cable, barn door |
| Environment: | IP 20 |
SKY PANEL 108
