Evacuation audio solutions
COMPACT TUTONDO VOICE ALARM SYSTEM EN54
Complete modular system for voice evacuation METCUBE, certified to EN 54-16, enclosed in a compact unit including power supply, control system, selective microphone.
Configuration, management, monitoring, via LAN network, using the software COMETA.
Free download control App for sound diffusion also available.
It fulfills all the EVAC requests, further adding useful features as multiroom functionality (for music and speech broadcasting) and interfaceability with the other external systems.
- EN54-16 certified
- Available in 2 version: up to 4 zones or up to 8 zones
- Expandable up to 540 W total wattage (1000W vocal), up to 8+1 power amplifiers (not included)
- Each amplifier drives a single speakers line
- Optional interfaces available for A-B double line (MET4SC o MET8SC)
- Built-in microphone and pre recorded messages, activatable from the front panel or remotely
- Possibility of sending messages / calls simultaneously on multiple zones
- 4 analog AUX monitored inputs
- 8 analog AUX not-monitored inputs (8 zones version only)
- Monitored trigger inputs for activating events (alarm, evacuation, etc) from the fire alarm central unit or other devices (8 on the 4 zones version; 16 on the 8 zones version)
- Compact unit complete with battery charger EN54-4 compliant and compartment for 2 batteries (up to 42 Ah)
- USB connector for firmware upgrades and configurations
- SD card reader to store EVAC messages and messages linked to events
- Digital bus "evac bus" dedicated for emergency paging stations (eg. METMC8C, METMC1A)
- Bus "remote bus" for interfacing with zone audio controls (eg. CZ830)
- RS232 serial port, Ethernet port
- Supports Modbus over TCP/IP
- Metallic case
Power supply: 230 Vac and 24 Vdc
Color: White (Ral 7035)
Dimensions: H 310 x W 432 x D 372 mm (7 RU)
Weight: 12.5 kg (without batteries and amplifier)
| METCUBE4Z27 | Compact main unit 4 single lines. 4 monitored analog inputs + 2 digital audio. 8 monitored ‘trigger’ inputs for activating events. 2x 27Ah batteries. |
| METCUBE4Z18 | Compact main unit 4 single lines. 4 monitored analog inputs + 2 digital audio. 8 monitored ‘trigger’ inputs for activating events. 2x 18Ah batteries. |
| METCUBE4Z42 | Compact main unit 4 single lines. 4 monitored analog inputs + 2 digital audio. 8 monitored ‘trigger’ inputs for activating events. 2x 42Ah batteries. |
| METCUBE8Z27 | Compact main unit 8 single lines. 4 monitored analog inputs + 8 unmonitored analog inputs + 2 digital audio. 16 monitored ‘trigger’ inputs for activating events. 2x 27Ah batteries. |
| METCUBE8Z42 | Compact main unit 8 single lines. 4 monitored analog inputs + 8 unmonitored analog inputs + 2 digital audio. 16 monitored ‘trigger’ inputs for activating events. 2x 42Ah batteries. |
| METCUBE8Z | Whithout batteries |
| METCUBE4Z | Whithout batteries |
METCUBE
Complete Compact main unit for voice evacuation systems, EN54-16 certified
SIMPLE type modular VERTICAL compact wall unit METCUBEVS, certified to EN 54-16, enclosed in a compact unit including power supply, amplifier section, control system, selective microphone.
Configuration, management, monitoring, via LAN network, using the software COMETA.
Free download control App for sound diffusion also available.
It fulfills all the EVAC requests, further adding useful features as multiroom functionality (for music and speech broadcasting) and interfaceability with the other external systems.
- EN54-16 certified
- Available in 4 zones version
- Expandable up to 240 W total wattage (500 W vocal), up to 4 (not included)
- Each amplifier drives a single speakers line
- Optional interfaces available for A-B double line (MET4SC)
- Built-in microphone and pre recorded messages, activatable from the front panel or remotely
- Possibility of sending messages / calls simultaneously on multiple zones
- 4 analog AUX monitored inputs
- 8 Monitored trigger inputs for activating events (alarm, evacuation, etc) from the fire alarm central unit or other devices
- Compact unit complete with battery charger EN54-4 compliant and compartment for 2 batteries (up to 35 Ah)
- USB connector for firmware upgrades and configurations
- SD card reader to store EVAC messages and messages linked to events
- Digital bus "evac bus" dedicated for emergency paging stations (eg. METMC8C, METMC1A)
- Bus "remote bus" for interfacing with zone audio controls (eg. CZ830)
- RS232 serial port, Ethernet port
- Supports Modbus over TCP/IP
- Metallic case
Power supply: 230 Vac and 24 Vdc
Color: White (Ral 7035)
Dimensions: H 400x W 432 x D 240 mm (9 RU)
Weight: 12.5 kg (without batteries and amplifier)
| METCUBE4Z18VS | Compact main unit 4 single lines. 4 monitored analog inputs + 2 digital audio. 8 monitored ‘trigger’ inputs for activating events. 2x 18Ah batteries. |
| METCUBE4Z27VS | Compact main unit 4 single lines. 4 monitored analog inputs + 2 digital audio. 8 monitored ‘trigger’ inputs for activating events. 2x 27Ah batteries. |
| METCUBE4Z35VS | Compact main unit 4 single lines. 4 monitored analog inputs + 2 digital audio. 8 monitored ‘trigger’ inputs for activating events. 2x 35Ah batteries. |
METCUBE
Compact modular vertical main unit (VS), for voice evacuation systems, EN54-16 certified
METMC8C
Paging station for voice calls for 8 zones selectable, or general emergency calls (all zones).
More zones available using the expansions MET8TZ or MET16TZ.
- EN54-16 certified
- Pre-recorded emergency messages sendable
- System status display
- Digital bus for communication with control units
- Compatible with MET8CV8, MET8CV4, METCUBE
Power supply: 24 Vdc
Overall dimensions: H55 x W205 x D190 mm
Weight: 2.1 kg
METMC8C
Paging station for voice messages, 8 zones selection or general emergency calls, a selection of pre-recorded emergency messages. EN54-16 certified.
METMC1AC
Microphone in cabinet, general emergency calls, 24 Vdc supply. EN54-16 certified.
PUBLIC ADDRESS COMMUNICATION, EN54 CERTIFIED.
Main unit complete with monitoring and displaying system MET8CV8 for voice evacuation.
The system is designed for connecting 8 single 100 V speaker lines.
Optional interface MET8SC available for doubling the lines.
Expandable system (up to 128 lines / zones) adding MET8CVE8 expansions.
System setup and managing by COMETA software.
Free download control app for sound diffusion available in free download.
- EN54-16 certified
- Built-in microphone and pre recorded messages that can be activated from the front panel or remotely
- Possibility of sending messages/calls simultaneously on multiple zones
- 4 monitored analog inputs + 8 unmonitored analog inputs
- 16 monitored trigger inputs for activating events (alarm, evacuation, etc) from the fire alarm central unit or other devices
- Main unit complete with 540 W power supply
- USB connector for firmware upgrades and configurations
- SD card reader to store EVAC messages and messages linked to events
- Digital bus evac bus dedicated for emergency paging stations (eg. METMC8C, METMC1A)
- Bus remote bus for interfacing with zone audio controls (eg. CZ830)
- RS232 serial port and Ethernet port
- Supports Modbus over TCP/IP
- Metal case designed for standard rack mounting 19"
Power supply: 230 Vac and 24 Vdc.
Color: Black.
Dimensions: H88 x W483 x D330 mm (2 RU).
Weight: 6.3 kg.
MET8CV8
Main unit complete with monitoring and displaying system for voice evacuation. 8 single lines. EN54-16 certified.
Main unit complete with monitoring and displaying system MET8CV4 for voice evacuation.
The system is designed for connecting 4 single 100 V speaker lines.
Optional interface MET4SC available for doubling the lines.
System setup and managing by COMETA Tutondo software.
Free download control App for sound diffusion also available.
- EN54-16 certified
- Built-in microphone and pre recorded messages that can be activated from the front panel or remotely
- Possibility of sending messages/calls simultaneously on multiple zones
- 4 monitored analog inputs
- 8 monitored trigger inputs for activating events (alarm, evacuation, etc) from the fire alarm central unit or other devices
- Main unit complete with 540 W power supply
- USB connector for firmware upgrades and configurations
- SD card reader to store EVAC messages and messages linked to events
- Proprietary bus for paging stations
- RS232 serial port and Ethernet port
- Supports Modbus over TCP/IP
- Metal case designed for standard rack mounting 19 "
Power supply: 230 Vac and 24 Vdc.
Color: Black.
Dimensions: H 88 x W 483 x D 330 mm (2 RU).
Weight: 6.3 kg.
MET8CV4
Main unit complete with monitoring and displaying system for voice evacuation EN54-16 certified
Power amplifier module MET18A1P 180 W, class D.
Built-in power supply with high efficiency.
EN54-16 compliant.
- Outputs for speaker lines: 100 V - 50 V - 33 V (removable terminals with screw)
- Output power: 180W (power supply 29 Vdc)
- Input sensitivity: 1 Vrms
- Balanced inputs and outputs, removable terminals with screw
- Frequency response: 68 Hz to 20,000 Hz
- Muting circuit to eliminate impulsive noise in switching on
- Protection against short circuit and overload
- Ventilation system for forced air cooling
- LED warning lights switch, signal presence and clip saturation with protection intervention
- Metallic case
- Installation in standards 19" rack cabinets with rails GRPW and desk PP3A2 up to 3 power supply, size 2 units
- up to 5 power supply with rails GRPW and desk PP5A3, size 3 units
Power supply: 230 Vac and 24 Vdc
Color: Black
Overall dimensions: H 88 x W 130 x D 420 mm
Weight: 4.2 Kg
