Τα νέα προγραμματισμένα σεμινάρια Digico που θα λαμβάνουν χώρα στην έδρα της
εταιρίας , Ι.Αγάθου 48 , Ελευσίνα, θα γίνονται σε ολιγομελή τμήματα 3 ατόμων
(το μέγιστο), σε εβδομαδιαία βάση.(Κάθε Τετάρτη 12:00)

Hear the Future

Απευθύνεται σε ηχολήπτες και ιδιοκτήτες Rental εταιρειών και είναι δωρεάν.

Στόχος αυτού του προγράμματος είναι η ανάδειξη των δυνατοτήτων των Desk της DiGiCo (S-21, SD-12)
και η σωστή κατάρτιση στον χειρισμό τους.

Αντικείμενο Σεμιναρίου :

• Τεχνολογία Stealth Digital Processing

• Συνδεσμολογία , πρωτόκολλο μετάδοσης ήχου

• Εξ’ αρχής κατασκευή νέου Show, layout

• Επίδειξη, επεξεργασία processing real time με πολύ-κάναλο playback

• Recording

• Snapshot , μακροεντολές, συντομεύσεις

Διάρκεια του σεμιναρίου 4-5 ώρες.

Δηλώστε συμμετοχή για να εξασφαλίσετε θέση σε ένα από τα σεμινάρια που θα

διεξαχθούν.

ΚΟΝΣΟΛΕΣ

S31 MAIN FEATURES

48 Flexi Input Channels
16 Flexi Aux / Sub-Group Busses
LR Master Bus
10 x 8 Full Processing Matrix
2 Solo
4 (To Follow) Dynamic Equalizers
4 Assignable DiGiTuBes
4 Assignable Multiband Compressors
8 Digital FX
16 Assignable Graphic Equalizers
Optional Waves Integration
96kHz Sample Rate
N/A Optics

S31 : Specifications

General Specifications

46 busses: 16 x flexi-busses Mono/Stereo (equivalent of 32 DSP busses), Stereo Master (2), Solo busses (2 stereo, 4 total), and 10 x 8 Matrix (8)
10 x Control Groups
1 x Compressor per channel and buss
1 x Gate per channel and buss (switchable to ducker, or compressor with side chain access)
16 x assignable 32 band Graphic EQs
8 x FX engines (reverbs, delays, w/modulation and enhancer)
4 x assignable DiGiTuBes
4 x assignable Multiband Comps
User definable Macros
An extremely high power headphone amplifier with 1/4 inch and mini jack socket
96kHz as standard
24 mic line inputs
12 analogue outs
2 AES I/O (mono)
Word Clock I/O
1 GPI and 1 GPO
DVI out (for an external monitor)
2 DMI Card slots (up to 64 I/O per slot)
2 Ethernet connections for Networking
2 x 24 segment master/solo meters
Touch sensitive rotaries with integrated switch & HTL
3 x multi-touch screens
31 x touch sensitive moving faders
4 x layers of banks of 10 faders
Customisable bank and channel layout
Snapshots
Integrated USB2 Audio I/O interface for recording and playback of up to 48 channels 40 x Input flex-channels Mono/Stereo (equivalent of 80 DSP channels)

Audio Specification

Sample Rate 48kHz, 96kHz
Processing Delay 2ms Typical @ 48k(60 Stereo Channels, Stage
Input Through L-R Buss to Stage Output) 1.1ms @ 96kHz
Internal Processing Up to 40-bit, Floating Point
A>D & D>A 24-bit Converter Bit Depth
Frequency Response +/- 0.6dB (20Hz – 20kHz)
THD <0.05% @ Unity Gain, 10dB Input @ 1kHz
Channel Seperation Better Than 90dB (40Hz – 15kHz)
Residual Output <90dBu Typical
Noise (20Hz - 20kHz)
Microphone Input Better Than -126dB Equivalent Noise
Maximum Output Level +22dBu
Maximum Input Level +22dBu

Processing Channel Specification
Input Channel

Input Name User-Defined
Channel Selection Mono / Stereo
Input Routing Main Input
Analogue Gain -20 to +60dB
Phase Normal / Reverse
Digital Trim 40 to +40dB
Delay 0 - 682ms
DiGiTuBe Drive 0.01 - 50.0
Bias 0 - 6
LPF 20 – 20kHz, 24dB/Oct
HPF 20 – 20kHz, 24dB/Oct
Insert A (Pre EQ/Dyn) On/Off
Equalisation 4 Band EQ: Parametric or Dynamic (Low/Lowshelf, Lower-Mid/Lowshelf, Upper-Mid/
Hishelf, Hi/Hishelf)
On/Off
Freq; 20 – 20kHz
Gain; +/- 18dB
Q: 0.1 -20 (Parametric) / 0.10-0.90 (Shelf)
Dynamics 1 Single or 4 x Multiband (3-Band)
Compressor On/Off
Threshold; -60 – 0dB
Attack; 500us – 100ms
Release; 5ms – 5s
Ratio; 1:1 – 50:1
Gain; 0 to +40dB
Hi Crossover; 20Hz – 20kHz
Lo Crossover; 20Hz – 20kHz
Knee : Hard, Med, Soft
Dynamics 2 On/Off
Gate / Ducker Threshold; -60 – 0dB
Attack; 50us – 100ms
Hold; 2ms – 2s
Release; 5ms – 5s
Range; 0 - 90dB
Key; Any Source
Key Listen
Freq/Width; 20 – 20kHz
Compressor On/Off
Threshold; -60 – 0dB
Attack; 500us – 100ms
Release; 5ms – 5s
Ratio; 1:1 – 50:1
Gain; 0 to +40dB
Link; Any Channel / Buss
S/C Source : Any Source
S/C Listen : On/Off
S/C Filter Freq/Width: 20Hz – 20kHz
Insert B (Post EQ/Dyn) On/Off
Mute Channel Mute
Solo Solo Buss 1 / Solo Buss 2 / Both,
Channel Safe Socket Properties, Input Route, Mono/Stereo, Label, Filters, Trim, Delay, Tube, Insert A, EQ, Dyn1, Dyn2, Insert B, Aux, Group Assigns, Pan, Fade, Mute, Direct Outs, Full Safe
Output Routing Buss,
Insert A, Insert B,
Direct: Post-Fade
Fader 100mm Motorised Fader ∞ to +10dB

Processing Channel Specification
Aux / Group / Matrix Output

Name User-Defined
Phase Normal / Reverse
Digital Trim -40 to +40dB
Delay 0 - 682ms
DiGiTuBe Drive 0.01 - 50.0 Bias 0 - 6
LPF 20 – 20kHz, 24dB / Oct
HPF 20 – 20kHz, 24dB / Oct
Insert A (Pre EQ/Dyn) On/Off
Equalisation 4 Band EQ: Parametric or Dynamic (Low/Lowshelf, Lower-Mid/Lowshelf, Upper-Mid/Hishelf, Hi/Hishelf)
On/Off
Freq; 20 – 20kHz
Gain; +/- 18dB
Q: 0.1 -20 (Parametric) / 0.10-0.90 (Shelf)
Dynamics 1 Single or 4 x Multiband (3-band)
Compressor On/Off
Threshold; -60 – 0dB
Attack; 500us – 100ms
Release; 5ms – 5s
Ratio; 1:1 – 50:1
Gain; 0 to +40dB
Hi Crossover; 20Hz – 20kHz
Lo Crossover; 20Hz – 20kHz
Knee : Hard, Med, Soft
Gate / Ducker Threshold; -60 – 0dB
Attack; 50us – 100ms
Hold; 2ms – 2s
Release; 5ms – 5s
Range; 0 - 90dB
Key; Any Source
Key Listen
Freq/Width; 20 – 20kHz
Compressor On/Off
Threshold; -60 – 0dB
Attack; 500us – 100ms
Release; 5ms – 5s
Ratio; 1:1 – 50:1
Gain; 0 to +40dB
Link; Any Channel/Buss
S/C Source : Any source
S/C Listen : On/Off
S/C Filter Freq/Width: 20Hz – 20kHz
Insert B (Post EQ/Dyn) On/Off
Mute Channel Mute
Solo Solo Buss 1 / Solo Buss 2 / Both,
Channel Safe Mono/Stereo, Bus Mode, Label, Filters, Trim, Delay, Tube, Insert A, EQ, Dyn1, Dyn2, Insert B, Group Assigns, Fade, Mute, Direct Outs,
Full Safe
Output Routing Outputs, Insert A, Insert B
Fader 100mm Motorised Fader ∞ to + 10dB

SEE MORE...

S21 MAIN FEATURES

48 Flexi Input Channels
16 Flexi Aux / Sub-Group Busses
LR Master Bus
10 x 8 Full Processing Matrix
2 Solo
4 (To Follow) Dynamic Equalizers
4 Assignable DiGiTuBes
4 Assignable Multiband Compressors
8 Digital FX
16 Assignable Graphic Equalizers
Optional Waves Integration
96kHz Sample Rate
N/A Optics

S21 : Specifications

General Specifications

46 busses: 16 x flexi-busses Mono/Stereo (equivalent of 32 DSP busses), Stereo Master (2), Solo busses (2 stereo, 4 total), and 10 x 8 Matrix (8)
10 x Control Groups
1 x Compressor per channel and buss
1 x Gate per channel and buss (switchable to ducker, or compressor with side chain access)
16 x assignable 32 band Graphic EQs
8 x FX engines (reverbs, delays, w/modulation and enhancer)
4 x assignable DiGiTuBes
4 x assignable Multiband Comps
User definable Macros
An extremely high power headphone amplifier with 1/4 inch and mini jack socket
96kHz as standard
24 mic line inputs
12 analogue outs
2 AES I/O (mono)
Word Clock I/O
1 GPI and 1 GPO
DVI out (for an external monitor)
2 DMI Card slots (up to 64 I/O per slot)
2 Ethernet connections for Networking
2 x 24 segment master/solo meters
Touch sensitive rotaries with integrated switch & HTL
2 x multi-touch screens
21 x touch sensitive moving faders
4 x layers of banks of 10 faders
Customisable bank and channel layout
Snapshots
Integrated USB2 Audio I/O interface for recording and playback of up to 48 channels 40 x Input flex-channels Mono/Stereo (equivalent of 80 DSP channels)

Audio Specification

Sample Rate 48kHz, 96kHz
Processing Delay 2ms Typical @ 48k(60 Stereo Channels, Stage
Input Through L-R Buss to Stage Output) 1.1ms @ 96kHz
Internal Processing Up to 40-bit, Floating Point
A>D & D>A 24-bit Converter Bit Depth
Frequency Response +/- 0.6dB (20Hz – 20kHz)
THD <0.05% @ Unity Gain, 10dB Input @ 1kHz
Channel Seperation Better Than 90dB (40Hz – 15kHz)
Residual Output <90dBu Typical
Noise (20Hz - 20kHz)
Microphone Input Better Than -126dB Equivalent Noise
Maximum Output Level +22dBu
Maximum Input Level +22dBu

Processing Channel Specification
Input Channel

Input Name User-Defined
Channel Selection Mono / Stereo
Input Routing Main Input
Analogue Gain -20 to +60dB
Phase Normal / Reverse
Digital Trim 40 to +40dB
Delay 0 - 682ms
DiGiTuBe Drive 0.01 - 50.0
Bias 0 - 6
LPF 20 – 20kHz, 24dB/Oct
HPF 20 – 20kHz, 24dB/Oct
Insert A (Pre EQ/Dyn) On/Off
Equalisation 4 Band EQ: Parametric or Dynamic (Low/Lowshelf, Lower-Mid/Lowshelf, Upper-Mid/
Hishelf, Hi/Hishelf)
On/Off
Freq; 20 – 20kHz
Gain; +/- 18dB
Q: 0.1 -20 (Parametric) / 0.10-0.90 (Shelf)
Dynamics 1 Single or 4 x Multiband (3-Band)
Compressor On/Off
Threshold; -60 – 0dB
Attack; 500us – 100ms
Release; 5ms – 5s
Ratio; 1:1 – 50:1
Gain; 0 to +40dB
Hi Crossover; 20Hz – 20kHz
Lo Crossover; 20Hz – 20kHz
Knee : Hard, Med, Soft
Dynamics 2 On/Off
Gate / Ducker Threshold; -60 – 0dB
Attack; 50us – 100ms
Hold; 2ms – 2s
Release; 5ms – 5s
Range; 0 - 90dB
Key; Any Source
Key Listen
Freq/Width; 20 – 20kHz
Compressor On/Off
Threshold; -60 – 0dB
Attack; 500us – 100ms
Release; 5ms – 5s
Ratio; 1:1 – 50:1
Gain; 0 to +40dB
Link; Any Channel / Buss
S/C Source : Any Source
S/C Listen : On/Off
S/C Filter Freq/Width: 20Hz – 20kHz
Insert B (Post EQ/Dyn) On/Off
Mute Channel Mute
Solo Solo Buss 1 / Solo Buss 2 / Both,
Channel Safe Socket Properties, Input Route, Mono/Stereo, Label, Filters, Trim, Delay, Tube, Insert A, EQ, Dyn1, Dyn2, Insert B, Aux, Group Assigns, Pan, Fade, Mute, Direct Outs, Full Safe
Output Routing Buss,
Insert A, Insert B,
Direct: Post-Fade
Fader 100mm Motorised Fader ∞ to +10dB

Processing Channel Specification
Aux / Group / Matrix Output

Name User-Defined
Phase Normal / Reverse
Digital Trim -40 to +40dB
Delay 0 - 682ms
DiGiTuBe Drive 0.01 - 50.0 Bias 0 - 6
LPF 20 – 20kHz, 24dB / Oct
HPF 20 – 20kHz, 24dB / Oct
Insert A (Pre EQ/Dyn) On/Off
Equalisation 4 Band EQ: Parametric or Dynamic (Low/Lowshelf, Lower-Mid/Lowshelf, Upper-Mid/Hishelf, Hi/Hishelf)
On/Off
Freq; 20 – 20kHz
Gain; +/- 18dB
Q: 0.1 -20 (Parametric) / 0.10-0.90 (Shelf)
Dynamics 1 Single or 4 x Multiband (3-band)
Compressor On/Off
Threshold; -60 – 0dB
Attack; 500us – 100ms
Release; 5ms – 5s
Ratio; 1:1 – 50:1
Gain; 0 to +40dB
Hi Crossover; 20Hz – 20kHz
Lo Crossover; 20Hz – 20kHz
Knee : Hard, Med, Soft
Gate / Ducker Threshold; -60 – 0dB
Attack; 50us – 100ms
Hold; 2ms – 2s
Release; 5ms – 5s
Range; 0 - 90dB
Key; Any Source
Key Listen
Freq/Width; 20 – 20kHz
Compressor On/Off
Threshold; -60 – 0dB
Attack; 500us – 100ms
Release; 5ms – 5s
Ratio; 1:1 – 50:1
Gain; 0 to +40dB
Link; Any Channel/Buss
S/C Source : Any source
S/C Listen : On/Off
S/C Filter Freq/Width: 20Hz – 20kHz
Insert B (Post EQ/Dyn) On/Off
Mute Channel Mute
Solo Solo Buss 1 / Solo Buss 2 / Both,
Channel Safe Mono/Stereo, Bus Mode, Label, Filters, Trim, Delay, Tube, Insert A, EQ, Dyn1, Dyn2, Insert B, Group Assigns, Fade, Mute, Direct Outs,
Full Safe
Output Routing Outputs, Insert A, Insert B
Fader 100mm Motorised Fader ∞ to + 10dB

SEE MORE

SD12 MAIN FEATURES

72 Input Channels
36 Aux / Sub-Group Busses
LR/LCR Master Bus
12 x 8 Full Processing Matrix
2 Solo
119 Dynamic Equalizers
119 DiGiTuBes
119 Multiband Compressors
12 Digital FX
16 Graphic Equalizers
Optional Waves Integration
48/96kHz Sample Rate
Optional Optics

SD12 : Specifications

General Specifications

Faders: 26 x 100mm touch-sensitive, motorised
Screens: 2 x 15” LCD high - resolution touch screens
Input Channels: 72
Busses: Up to 36 plus masters Aux / Group busses with full processing Mono / Stereo / LCR
Matrix: Up to 12 Input / 8 Outputs with full processing
Control Groups: Up to 12, selectable for VCA-style, Moving fader, Mute Group
Graphic Eq: 16 x 32-band, Gain +/- 12dB
Internal FX: Up to 12 stereo effects comprising of reverbs and delay/chorus/pitch/enhancer
Local I/O: 8 x mic/line I/O, 8 x AES I/O
MADI interface: 2 Interfaces, BNC connectivity
Optic interface: Optional
Sampling rates: 48kHz / 96kHz
GPI/GPO: 16
Ext Sync: Wordclock, AES, MADI, Optics
Physical: 1124 mm (w) x 795mm (d) x
Dimensions: 389 mm (h)
Weight: 42Kg (82 Kg with flightcase)
Power : 90V-260V, 50-60Hz, 150VA
Requirements: (140W)

Audio Specification

Sample rate: 96kHz / 48kHz
Processing delay: 1ms Typical (channel, SD Rack input through L-R buss to stage output @96kHz)
Internal processing: Up to 40-bit, floating point A>D & D>A 24-bit Converter Bit Depth
Frequency response: +/- 0.6dB (20Hz – 20kHz)
THD: <0.05% @ unity gain, 10dB input @ 1kHz
Channel Seperation: Better than 90dB (40Hz – 15kHz)
Microphone Input: Better than -126dB Equivalent Noise
Maximum Output Level: +22dBu:
Maximum Input Level: +22dBu:

Processing Channel Specification
Input Channel

Name: User-defined / Presets
Channel Selection: Mono / Stereo / Multi
Input Routing: Main & Alternate Input
Analogue Gain: -20 to +60dB
Phase: Normal / Reverse
Digital Trim: -40 to +40dB
Delay: >1 sec (coarse & fine control)
DiGiTuBe: Drive 0.01 - 50.0
Bias 0 - 6
LPF: 20 – 20kHz, 24dB / Oct
HPF: 20 – 20kHz, 24dB / Oct
Insert A: (pre eq/dyn) On/off
Equalisation: 4 band EQ: Parametric or Dynamic
(low/lowshelf, lower-mid/lowshelf, upper-mid/hishelf, hi/hishelf)
on/off
Freq; 20 – 20kHz
Gain; +/- 18dB
Q: 0.1 -20 (parametric) / 0.10-0.85 (shelf)
Dynamic Eq on/off
Over/under
Band on/off
Threshold; -60 – 0dB
Attack; 500us – 100ms
Release; 10ms – 10s
Ratio; 1:1 – 50:1
Dynamics 1: Single or multiband (3-band)
Compressor: on / off
Threshold; -60 – 0dB
Attack; 500us – 100ms
Release; 10ms – 10s
Ratio; 1:1 – 50:1
Gain; 0 to +40dB with Autogain option
Link; any channel / buss
Hi crossover; 20Hz – 20kHz
Lo crossover; 20Hz – 20kHz
Knee : hard, med, soft
De-Esser: Threshold : 20us – 20ms
Release : 1ms – 100ms
Ratio : 1:1 – 50:1
Ess-band : Listen on/off
Ess-band filter freq / width: 20Hz – 20kHz
Dynamics 2: on/off
Gate / Ducker: Threshold; -60 – 0dB
Attack; 50us – 100ms
Hold; 2ms – 2s
Release; 5ms – 5s
Range; 0 - 90dB
Key; Any source
Key listen
Freq/width; 20 – 20kHz
Compressor: on / off
Threshold; -60 – 0dB
Attack; 500us – 100ms
Release; 10ms – 10s
Ratio; 1:1 – 50:1
Gain; 0 to +40dB with Autogain option
Link; any channel / buss
Hi crossover; 20Hz – 20kHz
Lo crossover; 20Hz – 20kHz
s/c source : Any source
s/c listen : on/off
s/c filter freq / width: 20Hz – 20kHz
Insert B: (post eq/dyn) On/off
EQ/Dyn order: EQ/Dyn or Dyn/EQ
Mute: Channel mute / hard mute
Solo: Solo Buss 1 / Solo Buss 2 / Both, Auto solo
Channel Safe: Input, eq, dyn, aux, pan, fade/mute, inserts, buss, directs, full safe
Output Routing: Buss, Insert A, Insert B, FX
Direct: on/off, pre-mute / pre-fade / post-fade, level +/- 18dB
Fader: 100mm motorised fader ∞ to +10dB
