SPEAKERS
COMMERCIAL AUDIO
AIR04X
AIR series outdoor loudspeakers present superior performance and durability with full sound over a large listening area. Thanks to their elegant style and sturdy structure, they are the ideal speakers for listening to music in the pool, on the veranda or even in the boat. The adjustable mounting brackets supplied, allow to set up them vertically or horizontally, so as to integrate them perfectly into the surrounding environment. The IP46 / IP56 structure (depending on the model) is designed to withstand the rigours of the climate all year round due to the outdoor installation.
Features:
Vertically or horizontally mounted with the brackets /supplied supports
Tested to withstand snow, rain and salt
Suitable for use on the boat
The AIR04X 2-way full-range loudspeaker with IP46 waterproof protection is ideal for small outdoor or indoor installations and can be used in combination with DAD ARK208 sub.
The polypropylene cabinet provides complete protection against ultraviolet rays.
The grid is made of perforated aluminium, internally lined with waterproof fabric and open cell polyurethane foam.
The PROAUDIO logo can be rotated for vertical or horizontal installation.
-
IP rating: 46 for outdoor events
-
Dimensions (WxHxD): 141x230x170mm
-
Weight: 2.6kg
-
System type: passive 2 way
-
Low frequency:4'' woofer/1''v.c.
-
High frequency: 1'' dome tweeter/0.8''v.c.
-
Sensitivity: 88dB
-
Impedance: 16
-
SPL cont/peak: 103/109dB
-
Frequency response: 75-20.000Hz
-
Coverage angle HxV: 120x90°
-
Cross over frequency: 3500Hz
-
Protection: H.F. signal compression
-
Suggest HPF range: 160/180Hz
-
Recommended amplifier up to: 200W
-
Screw terminal IN/OUT: phoenix
-
Cabinet material: polypropilene
-
Sospension system: wall brackets (included)
-
AES/program power: 50/100W
-
SPL max: 109dB @1m (free field)
AIR04X
AIR series outdoor loudspeakers present superior performance and durability with full sound over a large listening area. Thanks to their elegant style and sturdy structure, they are the ideal speakers for listening to music in the pool, on the veranda or even in the boat. The adjustable mounting brackets supplied, allow to set up them vertically or horizontally, so as to integrate them perfectly into the surrounding environment. The IP46 / IP56 structure (depending on the model) is designed to withstand the rigours of the climate all year round due to the outdoor installation.
Features:Vertically or horizontally mounted with the brackets /supplied supports
Tested to withstand snow, rain and salt
Suitable for use on the boat
The AIR04T 2-way full-range loudspeaker with IP46 waterproof protection is ideal for small outdoor or indoor installations and can be used in combination with DAD ARK208 divers.
Equipped with a transformer for use in 100V systems.
The polypropylene cabinet guarantees complete protection against ultraviolet rays.
The grid is in perforated aluminium, internally covered in waterproof fabric and open cell expanded polyurethane.
The PROAUDIO logo can be rotated for vertical or horizontal installation.
-
System type: passive 2 way
-
Low frequency: 4'' woofer/1''v.c.
-
High frequency: 1'' dome tweeter/0.8''v.c.
-
AES/program power: 50/100W
-
Input 100 V: 12.5/25/50W
-
SPL max: 109dB @1m (free field)
-
Sensitivity: 88dB
-
Impedance: 16 Ohm
-
SPL cont/peak: 103/109dB
-
Frequency response: 75-20.000Hz
-
Coverage angle HxV: 120x90°
-
Cross over frequency: 3500Hz
-
Protection: H.F. signal compression
-
Suggest HPF range: 160/180Hz
-
Recommended amplifier up to: 100W
-
Input signal: Phoenix IN/OUT
-
Cabinet material: polypropilene
-
Sospension system: wall brackets (included)
-
IP rating: 46 for outdoor installations
-
Dimensions (WxHxD): 141x230x170mm
-
Weight: 3.2kg
AIR04T
AIR series outdoor loudspeakers present superior performance and durability with full sound over a large listening area. Thanks to their elegant style and sturdy structure, they are the ideal speakers for listening to music in the pool, on the veranda or even in the boat. The adjustable mounting brackets supplied, allow to set up them vertically or horizontally, so as to integrate them perfectly into the surrounding environment. The IP46 / IP56 structure (depending on the model) is designed to withstand the rigours of the climate all year round due to the outdoor installation.
Features:Vertically or horizontally mounted with the brackets /supplied supports
Tested to withstand snow, rain and salt
Suitable for use on the boat
The AIR06X two-way full-range loudspeaker with IP46 waterproof protection is ideal for small outdoor or indoor installations and can be used as a satellite in combination with DAD ARK208 divers.
The polypropylene cabinet guarantees complete protection against ultraviolet rays.
The grid is in perforated aluminium, internally covered in waterproof fabric and open cell expanded polyurethane.
The PROAUDIO logo can be rotated for vertical or horizontal installation.
-
System type: passive 2 way
-
Low frequency: 6'' woofer/1.5''v.c.
-
High frequency: 1'' driver/1''v.c.
-
AES/program power: 120/240W
-
SPL max: 116dB @1m (free field)
-
Sensitivity: 89dB
-
Impedance: 16 Ohm
-
SPL cont/peak: 110/116dB
-
Frequency response: 60-18.000Hz
-
Coverage angle HxV: 90x60°
-
Cross over frequency: 2400Hz
-
Protection: H.F. signal compression
-
Suggest HPF range: 140/180Hz
-
Recommended amplifier up to: 240W
-
Screw terminal IN/OUT: phoenix
-
Cabinet material: polypropilene
-
Sospension system: wall brackets (included)
-
IP rating:46 for outdoor installations
-
Dimensions (WxHxD): 182x362x224mm
-
Weight: 6.2kg
AIR06X
AIR series outdoor loudspeakers present superior performance and durability with full sound over a large listening area. Thanks to their elegant style and sturdy structure, they are the ideal speakers for listening to music in the pool, on the veranda or even in the boat. The adjustable mounting brackets supplied, allow to set up them vertically or horizontally, so as to integrate them perfectly into the surrounding environment. The IP46 / IP56 structure (depending on the model) is designed to withstand the rigours of the climate all year round due to the outdoor installation.
Features:Vertically or horizontally mounted with the brackets /supplied supports
Tested to withstand snow, rain and salt
Suitable for use on the boat
The AIR06T 2-way full-range loudspeaker with IP46 waterproof protection is ideal for small outdoor or indoor installations and can be used as a satellite in combination with DAD ARK208 divers.
Equipped with a transformer for use in 100V systems.
The polypropylene cabinet guarantees complete protection against ultraviolet rays.
The grid is in perforated aluminium, internally covered in waterproof fabric and open cell expanded polyurethane.
The PROAUDIO logo can be rotated for vertical or horizontal installation.
-
System type: passive 2 way
-
Low frequency: 6'' woofer/1.5''v.c.
-
High frequency: 1'' driver/1''v.c.
-
AES/program power: 120/240W
-
Input 100 V: 30/60/120W
-
SPL max: 116dB @1m (free field)
-
Sensitivity: 89dB
-
Impedance: 16 Ohm
-
SPL cont/peak: 110/116dB
-
Frequency response: 60-18.000Hz
-
Coverage angle HxV: 90x60°
-
Cross over frequency: 2400Hz
-
Protection: H.F. signal compression
-
Suggest HPF range: 140/180Hz
-
Recommended amplifier up to: 240W
-
Screw terminal IN/OUT: phoenix
-
Input signal: Phoenix IN/OUT
-
Cabinet material: polypropilene
-
Sospension system: wall brackets (included)
-
IP rating: 46 for outdoor installations
-
Dimensions (WxHxD): 182x362x224mm
-
Weight: 7.2kg
AIR06T
AIR12TCOAX
AIR series outdoor loudspeakers present superior performance and durability with full sound over a large listening area. Thanks to their elegant style and sturdy structure, they are the ideal speakers for listening to music in the pool, on the veranda or even in the boat. The adjustable mounting brackets supplied, allow to set up them vertically or horizontally, so as to integrate them perfectly into the surrounding environment. The IP46 / IP56 structure (depending on the model) is designed to withstand the rigours of the climate all year round due to the outdoor installation.
Features:
Vertically or horizontally mounted with the brackets /supplied supports
Tested to withstand snow, rain and salt
Suitable for use on the boat
The AIR12TCOAX 2-way full-range loudspeaker with IP56 waterproof protection is ideal for long distances in professional installations both indoors and outdoors.
The coaxial transducer allows uniform coverage and high intelligibility.
Equipped with a transformer for use in 100V systems.
The polypropylene cabinet guarantees complete protection against ultraviolet rays.
The grid is in perforated aluminium, internally covered in waterproof fabric and open cell expanded polyurethane.
-
IP rating: 56 for outdoor events
-
Dimensions (WxHxD): 407x410x443mm
-
Weight: 18kg
-
System type: passive 2 way coaxial design
-
Low frequency: 12'' woofer/3''v.c.
-
High frequency: 1'' driver/1.7''v.c.
-
Sensitivity: 98dB @1W/1m (free field)
-
Impedance: 8
-
SPL cont/peak: 122/128dB @1m (free field)
-
Frequency response: 55-18000Hz (±3dB)
-
Coverage angle HxV: 80x80°
-
Cross over frequency: 2200Hz
-
Protection: H.F. signal compression
-
Suggest HPF range: 120/160Hz
-
Recommended amplifier up to: 600W
-
Input signal: screw terminal IN/OUT
-
Cabinet material: polypropilene
-
Sospension system: wall brackets (included)
-
AES/program power:300/600W
-
Input 100 V: 75/150/300W
-
SPL max:128dB @1m (free field)
AIR12TCOAX
IP56
AIR series outdoor loudspeakers present superior performance and durability with full sound over a large listening area. Thanks to their elegant style and sturdy structure, they are the ideal speakers for listening to music in the pool, on the veranda or even in the boat. The adjustable mounting brackets supplied, allow to set up them vertically or horizontally, so as to integrate them perfectly into the surrounding environment. The IP46 / IP56 structure (depending on the model) is designed to withstand the rigours of the climate all year round due to the outdoor installation.
Features:The AIR08TCOAX 2-way full-range loudspeaker with IP56 waterproof protection is ideal for long distances in professional installations both indoors and outdoors.
The coaxial transducer allows uniform coverage and high intelligibility.
Equipped with a transformer for use in 100V systems.
The polypropylene cabinet guarantees complete protection against ultraviolet rays.
The grid is in perforated aluminium, internally covered in waterproof fabric and open cell expanded polyurethane.
Tested to withstand snow, rain and salt
Suitable for use on the boat
-
System type: passive 2 way coaxial design
-
Low frequency: 8'' woofer/2''v.c.
-
High frequency: 1'' driver/1.4''v.c.
-
AES/program power: 180/360W
-
Input 100 V: 45/90/180W
-
SPL max: 123dB @1m (free field)
-
Sensitivity: 96dB @1W/1m (free field)
-
Impedance: 8 Ohm
-
SPL cont/peak: 117/123dB@1m (free field)
-
Frequency response:80-18000Hz (±3dB)
-
Coverage angle HxV: 100x100°
-
Cross over frequency: 2500Hz
-
Protection: H.F. signal compression
-
Suggest HPF range: 120/160Hz
-
Recommended amplifier up to: 360W
-
Input signal: screw terminal IN/OUT
-
Cabinet material: polypropilene
-
Sospension system: wall brackets (included)
-
IP rating: 56 for outdoor installations
-
Dimensions (WxHxD): 300x302x334mm
-
Weight: 10kg
AIR08TCOAX
Micro speaker with a closed rear cap. Ideal for high-fidelity sound reproduction designed for ceiling mounting.
Features:
4 "woofer
Built-in constant voltage transformer
Lightweight body scratch-treated, high-density polyurethane
Suitable for indoor use
Quick and easy installation by a special holding system, with no need of screws or other fixing elements
-
Weight: 0.36kg
-
Diameter Ø: 149x63mm
-
Flush-mounting hole Ø: 132mm
-
System type: closed enclosure ceiling speaker
-
Full range: 4''
-
Sensitivity: 90dB @1W/1m (free field)
-
Constant voltage: 70/100 V
-
Frequency response: 160÷20.000Hz (±3dB)
-
Input signal: terminal with wire
-
AES/program power: 3/6W
-
Input 100 V: 1.5/3W
DS40TC
Features:
5" woofer with the diaphragm made of polypropylene.
1" dome tweeter with treated silk diaphragm.
Built-in, multi-tap constant voltage transformer.
Switch to select constant-voltage (70/100V) or constant-impedance (8 Ohm) modes.
Built-in low-inductance passive crossover.
Body made of high-density polyurethane, scratch-proof, lightweight and UV/weather resistant.
Protective perforated steel grille.
Connections by wire terminals on the back.
Adjustable wall bracket included.
-
System type: wall speaker
-
Low frequency: 5''
-
High frequency: 1''
-
AES/program power: 40/80W
-
Input 100 V: 2.5/5/10/20/40W
-
Sensitivity: 90dB@1W/1m (free field)
-
Impedance:Low impedence: 8 Ohm
-
Constant voltage: 70/100 V
-
Frequency response: 70÷20.000Hz (±3dB)
-
Input signal: terminal with wire
-
Dimensions (WxHxD): 196x295x157mm
-
Weight: 4.1kg
DK90T
Micro loudspeaker ideal for high-fidelity sound reproduction designed for wall mounting.Features:
3" polypropylene diaphragm woofer.
Built-in, constant voltage transformer.
Body made of high-density polyurethane, scratch-proof, lightweight and UV/weather resistant.
Suitable for indoor and outdoor use.
Connection through terminals on the back.
Buttonhole screw on the back side.
-
System type:wall speaker
-
Full range: 3''
-
AES/program power: 3/5W
-
Input 100 V: 1.5/3W
-
Sensitivity: 92dB @1W/1m (free field)
-
Constant voltage:70/100 V
-
Frequency response: 150÷15.000Hz (±3dB)
-
Input signal: terminal with wire
-
Dimensions (WxHxD): 130x130x60mm
-
Weight: 0.4kg
DK30T
Compact horn speaker with a driver, high directivity and efficiency, ideal for intelligible sound and vocal reproduction.
Features:
Working in 8 Ohm lines or in 70/100V constant voltage lines thanks to the built-in transformer.
Hi-pass filter to protect driver against out-of-range low-frequencies.
IP66 construction for indoor-outdoor environmental temperatures between -25°C to 70°C.
Body in UV-stabilized ABS, white colour.
Steel fixing base included.
-
IP rating: 66
-
Dimensions (WxHxD):285x280x227mm
-
Weight: 1.36kg
-
System type: compact horn speaker
-
High frequency:1.7''
-
Sensitivity: 108dB @1W/1m (free field)
-
Impedance: Low impedence 8 Ohm
-
Constant voltage: 70/100 V
-
Frequency response: 250÷10000Hz (±3dB)
-
Input signal: terminal with wire
-
AES/program power:30/60W
-
Input 100 V: 15/30W
HD63T
DK88T
Bidirectional loudspeaker ideal for high-fidelity audio reproduction designed for ceiling and wall fixing.
Features:Two 6.5" woofers counterposed
Built-in constant voltage transformer.
Light body in white aluminium.
Protective perforated steel grille.
Protection: IP55, for temporary outdoor use
Connections by cable placed on top.
Adjustable wall bracket included.
-
System type: bidirectional wall speaker
-
Full range: 2x6.5''
-
AES/program power: 20/40W
-
Input 100 V: 10/20W
-
Sensitivity: 92dB @1W/1m (free field)
-
Constant voltage: 70/100 V
-
Frequency response: 150÷14.000Hz (±3dB)
-
Input signal: terminal with wire
-
Weight: 3.4kg
-
Diameter Ø: 190 x (252 deep)mm
Volume control: 4 positions + OFF.
AT60
Inputs: 1 micro XLR - 1 line with 2 x RCA
CAT5 / RJ45 connection
Dimensions 80x80x50
Weight 0.5 kg
WP1
